SE204 4-Electrode Conductivity Sensor | Epoxy Body | For media with medium to high conductivity

Product number: SE204
Compare
Compare
Description Technical details Downloads Use cases Blog posts

Description

SE204 4-Electrode Conductivity Sensor | Epoxy Body | For media with medium to high conductivity

4-Electrode Conductivity Sensor with Epoxy Body

  • 4 graphite electrodes
  • Epoxy body
  • Integrated temperature detector
  • Immersion depth min. 36 mm

The SE204 sensor with epoxy body is a sensor for conductivity measurements of media with medium to high conductivity. It has an integrated temperature detector.

Applications
Water/wastewater treatment



We look forward to hearing from you!
Contact Us

Technical details

Body Length: 120 mm / 4.72 inches
Body diameter: 15.3 mm / 0.60 inches
Connecting head material: POM
Electrodes: 4 graphite electrodes
Isolator: POM
Measurement Parameter: Conductivity
Seal: Viton
Measuring Range: 1 μS/cm ... 500 mS/cm
Temperature: –5 … 100 °C (23 ... 212 °F)
Temperature Detector: NTC 30 kΩ
Body Material: Epoxy, black
Immersion Depth: Min. 36 mm / 1.42 inches
Pressure: 2 bar (relative)
Cable: Fixed cable (length: 1.5 m / 5.90 ft)
Cell constant: 0.475 cm-1 ± 1.5 %
Resolution: Dependent on measuring range

Downloads

Manuals

[2125] User Manual (DE, EN, FR)
SE204 Conductivity Sensor
Version 01

Data Sheets

[18013] Data Sheet
SE204 Conductivity Sensor
Product Description | Specifications | Product Range

Certificates

[14516] EU Declaration of Conformity (DE, EN, FR)
No. EU210621A | 2021-06-21
Analog Sensors, non Ex
