用于电动汽车的电气测量技术 - 适合高压应用的可靠设备

电气化在各种类别和类型的车辆中发挥着越来越重要的作用。驱动和车辆部件的发展日新月异。对于电池来说尤其如此，电池的效率、尺寸以及充电时间和容量都在不断改进。

电池电压升高，对检测过程的要求不断提高

为了提高车辆性能，趋势显然是更高的电压。目前市场上已有系统电压为 800 V 的乘用车。部分重型车辆达到 1000 V 以上的电压，并且已经在规划 1250 V 或 1500 V DC 系统。特种车辆（例如采矿）的直流电压更高，可达 3.6 kV。由于充电电缆的可操作性，不能任意提高电流，若要实现高充电功率，就必须提高电压。

每辆电动汽车和混动汽车中都安装了大量高压组件，在开发和量产过程中必须检测这些部件的功能、安全性和可靠性。根据汽车行业的现行标准，还需要进行广泛的检测来鉴定部件。

为何选择 Knick?
对于要求苛刻的测量和检测任务，Knick 开发有各种用于在高压范围内测量电流和电压的高精度隔离变送器。此外，也有高度隔离、快速且精准的测量变送器，用于控制高电位下的检测设备。Knick 既提供种类齐全的标准产品，也能够根据应用的具体要求开发定制解决方案。

H2 [Ind] Application Description

Absatz [Ind] briefly: where can be used Knick products
电动汽车手册


电动汽车领域测试和测量特定应用及产品解决方案总览

相关应用

功率硬件在环 (HIL)
借助 HIL 测试，可以在各种电池、负载和故障情况下评估牵引逆变器等设备的原型，不必在试验台上或车辆中测试逆变器。
检测电池管理系统 (BMS)
测试系统在电池模型中产生控制电压，以便模拟电池管理系统的温度条件，并评估 BMS 的温度管理。
电池循环测试仪
在电池测试过程中，通过 HIL 配置（硬件在环）持续模拟充电和放电过程（电池循环），该配置与电动汽车运行期间的典型使用情况相对应。所测量的一系列参数包括容量、电池效率和自放电。
在线检测高压加热器 (HVH)
生产过程中使用的检测单元通常由防护罩和电压检测器保护。
车辆与充电站之间接口的直流电压测量
可以通过受电弓为电动商用车快速充电。为此需要在（带活动受电弓的）外部基础设施系统和固定安装在车顶上的充电杆之间保持接触。直流车顶配电箱包含检查充电连接和相应电压、以及与其他车载系统建立连接的组件。
工厂检测单元中的电气安全
生产过程中使用的检测单元通常由防护罩和电压检测器保护。

您有疑问吗？我们竭诚为您服务。
联系我们

合适的产品

A26000 Universal Isolated Signal Conditioner | Input 0…±20 mA or 0…±10 V | Current and voltage measurement
A26000 Universal Isolated Signal Conditioner | Input 0…±20 mA or 0…±10 V | Current and voltage measurement
商品编码:

A26000

P15000 Isolated Standard Signal Conditioner | Input and Output 0(4) … 20 mA or 0 … 10 V | Isolation up to 1000 V
P15000 Isolated Standard Signal Conditioner | Input and Output 0(4) … 20 mA or 0 … 10 V | Isolation up to 1000 V
商品编码:

P15000

P29000 High Voltage Transducer | Calibrated range selection
P29000 High Voltage Transducer | Calibrated range selection
商品编码:

P29000

P41000 High Voltage Transducer | Input up to ±100 V | High isolation up to 3600 V
P41000 High Voltage Transducer | Input up to ±100 V | High isolation up to 3600 V
商品编码:

P41000

P42000 High Voltage Transducer | Calibrated range selection
P42000 High Voltage Transducer | Calibrated range selection
商品编码:

P42000
