工厂检测单元中的电气安全

电池、功率电子装置、加热装置和电力车轴驱动装置等高压组件在安装到车辆上之前，必须检查其功能和安全性。为确保安全完成该工作，生产过程中使用的检测单元周围通常都有防护罩，以免危及设备附近的人员。

主要应用事实

领域


工厂检测单元中的电气安全

应用


可靠确认不再有高压

测量参数


一旦达到用户定义的阈值，就发出基于开关阈值的输出信号。

主要要求


确保高压环境内的工作场所安全

精确感测不安全电压极限

确认系统运行

通过检测危险高电压确保安全

应用说明

必须按照 EN 50191（或安装所在国/地区的类似标准和安全规定）保护检测工位。

应用的要求

由于组件的鉴定过程通常涉及在负载下进行检测，因此可靠确认不再有任何高压是工作人员能够重新安全进入检测单元的重要先决条件。

为何选择 Knick ?
Knick P52000VPD 传感器坚固耐用，一旦达到用户定义的阈值，就会提供基于开关阈值的输出信号。可以借助电压检测器监测高达 ± 4200 V AC/DC 的电压，永久隔离电压高达 4800 V AC/DC。可用的诊断开关输出确认“Power Good”状态。设备外壳带有硬化碳纤维防护罩，可防止输入端子出现高压。

相关产品

P52000 VPD High Voltage Transducer | Input max. 4200 V DC or AC peak | Voltage presence detection
P52000 VPD High Voltage Transducer | Input max. 4200 V DC or AC peak | Voltage presence detection
商品编码:

P52000VPD
