SE557 pH Sensor | Memosens | 250 mm | Ex | Alpha glass | For process media requiring high measurement stability
商品编号:
SE557X/2-NMSN
Description
SE557 pH Sensor | Memosens | 250 mm | Ex | Alpha glass | For process media requiring high measurement stability
For special requirements and high-precision measurements with refillable liquid electrolyte, digital, with Memosens technology
- High accuracy
- Extensive measuring range for pH and temperature
- Refillable liquid electrolyte
- 2 ceramic junctions
- Self cleaning due to pressurization
- Integrated temperature detector
- Alpha glass, medium impedance, universal glass, fluoride resistant
- Perfect galvanic isolation thanks to Memosens technology
- No influence of humidity in the connector
- Precalibration in the lab
- Digital data transfer
- Integrated sensor diagnostics
Elimination of typical junction problems resulting in high measurement accuracy in ultrapure water as well as in heavily polluted media and at high temperatures. Integrated, refillable liquid electrolyte reservoir. 2 ceramic junctions, self cleaning due to pressurization (continuous outflow of electrolyte).
我们期待您的来信
联系我们
| 传感器材料: | Alpha 玻璃 |
|---|---|
| 参考系统: | 银/氯化银，可补充液态电解质 |
| 插接头: | Memosens |
| 是否防爆: | Ex |
| 测量参数: | pH |
| 测量范围: | 0 … 14 pH |
| 温度: | -20 … 100 °C |
| 温度检测器: | NTC 30 kΩ |
| 相对压力: | -1 … 6 bar |
| 长度: | 250 mm |
| 隔膜: | 陶瓷 (2x) |
