SE558 pH 传感器 | VP | 120 mm | 防爆 | 适用于超纯水、水和工艺化学
商品编号:
SE558X/1-NVPN
Description
SE558 pH 传感器 | VP | 120 mm | 防爆 | 适用于超纯水、水和工艺化学
在超纯水、水和工艺化学领域轻松实现测量。
- 维护工作量小，不用补充电解质
- 内置温度探头
- 3 个陶瓷隔膜
- 不受流量影响
- KCl 储罐
- Alpha 玻璃：中等阻抗，通用玻璃，耐氟化物
低维护 pH 传感器，采用凝胶状参比电解质。传感器 SE558 集成有温度探头，可在传感器校准和运行期间对 pH 信号进行自动温度补偿。
传感器 SE558 特别适合用于低电导率介质。它配有 3 个陶瓷隔膜和一个 KCl 储罐。
应用领域
锅炉给水、冷凝水、超纯水、水管理、WFI（注射用水）。
我们期待您的来信
联系我们
| 传感器材料: | Alpha 玻璃 |
|---|---|
| 参考系统: | 银/氯化银、电解质凝胶、食盐供应 |
| 工艺连接: | PG 13.5 |
| 插接头: | VP (VarioPin) |
| 是否防爆: | Ex |
| 测量参数: | pH |
| 测量范围: | 0 … 14 pH |
| 温度: | –5 … 100 °C (23 ... 212 °F) |
| 温度检测器: | Pt1000 |
| 长度: | 120 mm |
| 隔膜: | 陶瓷, 3x |
